Burners

Crosstown carries a complete line of both oil and gas burners for use in a wide variety of residential and commercial applications. Typical applications include residential furnaces, commercial/industrial furnaces, boilers, water heaters, equipment for heat treating, incineration, paint drying, and essentially anywhere that the controlled conversion of fuel to flame is required.

Oil to Gas Conversion Burners

If you are interested in burners for conversion from oil to gas, look no further. Crosstown carries the Wayne Combustion- P250A capable of delivering up to 250,000 BTU/hr and easily one of the most reliable units on the market. See the table below for the full line of Gas Burners from Wayne,

Designed for performance, these gas burners are equally impressive for being easy to install and service.

FIRING RATE CAPABILITIES

GAS BURNERS

BTU/HR.

AIR TUBE INFORMATION

MODEL

MINIMUM

MAXIMUM

TUBE DIA.

WHOLESALE TUBE LENGTHS (SEE NOTE)

OEM TUBE LENGTHS

SC80

10,000

85,000

3″

4″ MAX. INSERTION

4 3/4″ MAX. INSERTION

P265F

65,000

200,000

4″

5″, 8″ & 11″

5″, 8″ & 11″

P250AF

50,000

250,000

4″

8″

8″

HSG200

60,000

200,000

4″

6″, 9″ & 12″

6″, 9″ & 12″

HSG400

200,000

400,000

4″

6 1/4″, 9″ & 12″

6 1/4″, 9″ & 12″

EHG

425,000

700,000

4″

6″, 9″, 12″ & 15″

6″, 9″, 12″ & 15″

LC1500

700,000

1,500,000

6.30″ a

5.49″

5.49″

LC2300

1,100,00

2,300,000

8.96″ a

6.19″

6.19″

NOTE – When an Adjustable Flange Assembly is utilized, maximum insertion is reduced 1″ (thickness of assembly).

a Maximum diameter.

Oil Burners

Oil BurnersOur favorite oil based burners come from Beckett, a long standing manufacturer of highly reliable and advanced burner products. In thier AFG burner, technically advanced components meet increased demand for improved burner performance in high-efficiency appliances and modern well-insulated homes. These advanced components are available on their B2000 series chassis and are used on a growing number of OEM appliances.

Specifications
Capacity

  • 0.40 – 3.00 GPH
  • 56,000 – 420,000 btu/hr input

Fuels

  • No.1 or No.2 heating oil (ASTM D396) only

Dimensions (standard)

  • Height: 11-1/2”
  • Width: 12-7/8”
  • Depth: 6-9/16” (chassis only)



Crosstown also carries Hi-BTU commercial Burners designed for use in industrial settings, or combined oil-gas burners for use in rental properties and apartment buildings where city codes require uninterrupted heat delivery.
